Description
Spefication of YBSD Series Water Cooling Double Speed Explosion-proof Motor for Scraper Conveyor
| Type |
Output (kW) |
Voltage (V) |
Current (A) |
Synchronous Speed (r/min) |
Eff. (%) |
Power Factor (Cos φ) |
Tm | Tst | Ist | Insulation Class | Cooling Type |
|---|---|---|---|---|---|---|---|---|---|---|---|
| YВSD-18,5/10-4/8 | 18,5/10 | 660 | 23.5/19.4 | 1500/750 | 86/82 | 0,80/0,55 | 2,5/- | 2,5/3,0 | 7,0/6,0 | H | Air-Cooling |
| YВSD-30/17-4/8 | 30/17 | 660 | 35.4/30.9 | 1500/750 | 88/83 | 0,83/0,58 | 2,5/- | 2,5/3,0 | 7,0/6,0 | H | Air-Cooling |
| YВSD-40/22-4/8 | 40/22 | 660 | 47.9/40.9 | 1500/750 | 88/81 | 0,83/0,58 | 2,5/- | 2,5/3,0 | 7,0/6,0 | H | Air-Cooling |
| YВSD-55/28-4/8 | 55/28 | 660 | 64.4/49.8 | 1500/750 | 89/82 | 0,84/0,6 | 2,5/- | 2,5/3,0 | 7,0/6,0 | H | Air-Cooling |
| YВSD-75/37-4/8 | 75/37 | 660 | 82.0/54.3 | 1500/750 | 92/89 | 0,87/0,67 | 2,5/- | 2,5/3,0 | 6,5/5,5 | H | Air-Cooling |
| YВSD-75/37-4/8 | 75/37 | 1140 | 47.5/31.4 | 1500/750 | 92/89 | 0,87/0,67 | 2,5/- | 2,5/3,0 | 6,5/5,5 | H | Air-Cooling |
| YВSD-90/45-4/8 | 90/45 | 660 | 98.4/66.0 | 1500/750 | 92/89 | 0,87/0,67 | 2,5/- | 2,5/3,0 | 6,5/5,5 | H | Air-Cooling |
| YВSD-90/45-4/8 | 90/45 | 1140 | 56.9/38.2 | 1500/750 | 92/89 | 0,87/0,67 | 2,5/- | 2,5/3,0 | 6,5/5,5 | H | Air-Cooling |
| YВSD-110/55-4/8 | 110/55 | 660 | 117.6/76.4 | 1500/750 | 93/90 | 0,88/0,70 | 2,4/- | 2,4/2,7 | 6,5/5,5 | H | Air-Cooling |
| YВSD-110/55-4/8 | 110/55 | 1140 | 68.1/44.2 | 1500/750 | 93/90 | 0,88/0,70 | 2,4/- | 2,4/2,7 | 6,5/5,5 | H | Air-Cooling |
| YВSD-132/65-4/8 | 132/65 | 660 | 141.1/90.3 | 1500/750 | 93/90 | 0,88/0,70 | 2,4/- | 2,4/2,7 | 6,5/5,5 | H | Air-Cooling |
| YВSD-132/65-4/8 | 132/65 | 1140 | 81.7/52.3 | 1500/750 | 93/90 | 0,88/0,70 | 2,4/- | 2,4/2,7 | 6,5/5,5 | H | Air-Cooling |
| YВSD-160/80-4/8 | 160/80 | 660 | 170.0/111.1 | 1500/750 | 93.5/90 | 0,88/0,70 | 2,4/- | 2,4/2,7 | 6,5/5,5 | H | Water-Cooling |
| YВSD-160/80-4/8 | 160/80 | 1140 | 98.5/64.3 | 1500/750 | 93.5/90 | 0,88/0,70 | 2,4/- | 2,4/2,7 | 6,5/5,5 | H | Water-Cooling |
| YВSD-200/100-4/8 | 200/100 | 1140 | 121.1/78.4 | 1500/750 | 93.5/91 | 0,89/0,71 | 2,4/- | 2,4/2,7 | 6,5/5,5 | H | Water-Cooling |
| YВSD-250/125-4/8 | 250/125 | 1140 | 149.7/97.4 | 1500/750 | 94/91.5 | 0,90/0,71 | 2,4/- | 2,4/2,7 | 6,5/5,5 | H | Water-Cooling |
| YВSD-300/150-4/8 | 300/150 | 1140 | 181.6/116.9 | 1500/750 | 94/91.5 | 0,89/0,71 | 2,2/- | 2,3/2,5 | 6,0/5,0 | H | Water-Cooling |
| YВSD-315/160-4/8 | 315/160 | 1140 | 188.2/119.4 | 1500/750 | 94.2/91.5 | 0,89/0,71 | 2,2/- | 2,3/2,5 | 6,0/5,0 | H | Water-Cooling |
| YВSD-375/188-4/8 | 375/188 | 1140 | 224.0/142.1 | 1500/750 | 94.2/91.5 | 0,90/0,73 | 2,2/- | 2,3/2,5 | 6,0/5,0 | H | Water-Cooling |
| YВSD-375/188-4/8 | 375/188 | 3300 | 74.4/49.1 | 1500/750 | 94.2/91.5 | 0,90/0,73 | 2,2/- | 2,3/2,5 | 6,0/5,0 | H | Water-Cooling |
| YВSD-400/200-4/8 | 400/200 | 1140 | 239.0/151.6 | 1500/750 | 94.2/91.5 | 0,90/0,73 | 2,2/- | 2,3/2,5 | 6,0/5,0 | H | Water-Cooling |
| YВSD-400/200-4/8 | 400/200 | 3300 | 82.5/52.4 | 1500/750 | 94.2/91.5 | 0,90/0,73 | 2,2/- | 2,3/2,5 | 6,0/5,0 | H | Water-Cooling |
| YВSD-450/225-4/8 | 450/225 | 3300 | 92.6/57.1 | 1500/750 | 94.2/91.5 | 0,90/0,73 | 2,2/- | 2,3/2,5 | 6,0/5,0 | H | Water-Cooling |
| YВSD-525/263-4/8 | 525/263 | 3300 | 180.0/66.6 | 1500/750 | 94.2/91.5 | 0,90/0,73 | 2,2/- | 2,3/2,5 | 6,0/5,0 | H | Water-Cooling |
| YВSD-700/350-4/8 | 700/350 | 3300 | 144.0/87.4 | 1500/750 | 94.2/91.5 | 0,90/0,73 | 2,2/- | 2,3/2,5 | 6,0/5,0 | H | Water-Cooling |
| YВSD-800/400-4/8 | 800/400 | 3300 | 164.6/101.4 | 1500/750 | 94.2/91.5 | 0,90/0,73 | 2,2/- | 2,3/2,5 | 6,0/5,0 | H | Water-Cooling |
| YВSD-900/450-4/8 | 900/450 | 3300 | 185.1/114.1 | 1500/750 | 94.2/91.5 | 0,90/0,73 | 2,2/- | 2,3/2,5 | 6,0/5,0 | H | Water-Cooling |
| YВSD-1000/500-4/8 | 1000/500 | 3300 | 205.2/126.8 | 1500/750 | 94.2/91.5 | 0,90/0,73 | 2,2/- | 2,3/2,5 | 6,0/5,0 | H | Water-Cooling |
