YBF2 Flameproof Electric Motors for Underground Mining Local Ventilators

Description

Spefication of YBF2 Flameproof Electric Motors for Underground Mining Local Ventilators

Type	Power (KW)	Current （A） 380V	Current （A） 660V	Current （A） 1140V	Speed 50HZ	Efficiency (%)	Power factor （cosΦ）	Noise dB(A)	Vibration (mm/s)	Tst/Tn	Ist/In	Tmax/Tn	Weight (Kg)
YBF2-631-2	0.18kW	0.5	0.29	0.17	2820	66	0.8	61	1.8	2.2	5	2.3	12
YBF2-632-2	0.25kW	0.66	0.38	0.22	2820	68	0.81	61	1.8	2.2	5	2.3	15
YBF2-711-2	0.37kW	0.96	0.55	0.32	2830	70	0.81	64	1.8	2.2	5.5	2.3	16
YBF2-712-2	0.55kW	1.33	0.77	0.45	2840	73	0.83	64	1.8	2.2	5.5	2.3	18
YBF2-801-2	0.75kW	1.8	1.04	0.6	2850	75	0.83	67	1.8	2.2	6	2.3	21
YBF2-802-2	1.1kW	2.6	1.5	0.87	2840	78	0.84	67	1.8	2.2	6	2.3	23
YBF2-90S-2	1.5kW	3.4	1.96	1.13	2850	79	0.84	72	1.8	2.2	7	2.3	32
YBF2-90L-2	2.2kW	4.8	2.76	1.6	2850	81	0.85	72	1.8	2.2	7	2.3	36
YBF2-100L-2	3kW	6.2	3.57	2.07	2870	83	0.88	76	1.8	2.2	7	2.3	42
YBF2-112M-2	4kW	8.1	4.66	2.7	2890	85	0.88	77	1.8	2.2	7	2.3	53
YBF2-132S1-2	5.5kW	11.1	6.39	3.7	2900	86	0.88	80	1.8	2.2	7.5	2.3	78
YBF2-132S2-2	7.5kW	14.8	8.52	4.93	2900	87	0.88	80	1.8	2.2	7.5	2.3	86
YBF2-160M1-2	11kW	21.6	12.44	7.2	2940	88	0.88	86	2.8	2.2	7.5	2.4	133
YBF2-160M2-2	15kW	28.8	16.58	9.6	2940	89	0.89	86	2.8	2.2	7.5	2.4	148
YBF2-160L-2	18.5kW	35.5	20.44	11.83	2940	89	0.89	86	2.8	2.2	7.5	2.4	166
YBF2-180M-2	22kW	41	23.61	13.67	2950	90.5	0.9	89	2.8	2	7.5	2.3	209
YBF2-200L1-2	30kW	55.5	31.95	18.5	2950	91.2	0.9	92	2.8	2	7.5	2.4	289
YBF2-200L2-2	37kW	67.9	39.09	22.63	2950	92	0.9	92	2.8	2	7.5	2.4	303
YBF2-225M-2	45kW	82.1	47.27	27.37	2960	92.5	0.9	92	2.8	2	7.5	2.3	278
YBF2-250M-2	55kW	99.7	57.4	33.23	2970	92.5	0.9	93	3.5	2.1	7.5	2.3	446
YBF2-280S-2	75kW	134.4	77.38	44.8	2970	93.2	0.91	94	3.5	2	7.5	2.3	635
YBF2-280M-2	90kW	160.7	92.52	53.56	2970	93.8	0.91	94	3.5	2.1	7.5	2.3	708
YBF2-315S-2	110kW	195.4	112.5	65.13	2982	94	0.91	96	3.5	1.8	7	2.3	998
YBF2-315M-2	132kW	232.2	133.69	77.4	2982	94.5	0.91	96	3.5	1.8	7	2.3	1035
YBF2-315L1-2	160kW	279.3	160.81	93.1	2982	94.6	0.92	99	3.5	1.8	7	2.3	1345
YBF2-315L2-2	200kW	348.8	200.82	116.26	2982	94.8	0.92	99	3.5	1.8	7	2.3	1600
YBF2-355S1-2	185kW	323	185.97	107.67	2980	94.6	0.92	99	3.5	1.8	7	2.3	1690
YBF2-355S2-2	200kW	348.4	200.59	116.13	2980	94.8	0.92	99	3.5	1.8	7	2.3	1690
YBF2-355M1-2	220kW	383.3	220.69	127.77	2980	94.8	0.92	103	3.5	1.6	7	2.4	1860
YBF2-355M2-2	250kW	443.2	255.18	147.74	2980	95.3	0.92	103	3.5	1.6	7	2.4	2100
YBF2-355L1-2	280kW	485.4	279.47	161.8	2980	95.3	0.92	103	3.5	1.6	7	2.4	2250
YBF2-355L2-2	315kW	544.2	313.33	181.4	2980	95.6	0.92	103	3.5	1.6	7	2.4	2280
YBF2-631-4	0.12kW	0.5	0.29	0.17	1350	58	0.72	52	1.8	2	4	2.2	13
YBF2-632-4	0.18kW	0.66	0.38	0.22	1360	63	0.73	52	1.8	2	4	2.2	15
YBF2-711-4	0.25kW	0.96	0.55	0.32	1370	66	0.74	55	1.8	2	4	2.2	17
YBF2-712-4	0.37kW	1.33	0.77	0.45	1380	69	0.75	55	1.8	2	4	2.2	19
YBF2-801-4	0.55kW	1.5	0.86	0.5	1390	71	0.75	58	1.8	2.4	5	2.3	21
YBF2-802-4	0.75kW	2	1.15	0.67	1390	73	0.77	58	1.8	2.4	5	2.3	23
YBF2-90S-4	1.1kW	2.9	1.67	0.97	1390	75	0.77	61	1.8	2.3	6	2.3	32
YBF2-90L-4	1.5kW	3.7	2.13	1.23	1390	78	0.79	61	1.8	2.3	6	2.3	36
YBF2-100L1-4	2.2kW	5.1	2.94	1.7	1420	80	0.81	64	1.8	2.3	6	2.4	42
YBF2-100L2-4	3kW	6.8	3.92	2.27	1420	82	0.82	64	1.8	2.3	6	2.4	53
YBF2-112M-4	4kW	8.8	5.07	2.94	1430	84	0.82	65	1.8	2.3	6	2.4	78
YBF2-132S1-4	5.5kW	11.5	6.62	3.83	1450	86	0.84	71	1.8	2.3	7	2.4	86
YBF2-132M-4	7.5kW	15.4	8.87	5.14	1450	87	0.85	71	2.8	2.3	7	2.4	133
YBF2-160M-4	11kW	22.3	12.84	7.43	1460	88	0.85	75	2.8	2.2	7	2.4	148
YBF2-160L-4	15kW	30.1	17.33	10.03	1460	89	0.85	75	2.8	2.2	7	2.4	166
YBF2-180M-4	18.5kW	36.5	21.02	12.17	1470	90	0.85	76	2.8	2.2	7	2.3	209
YBF2-180L-4	22kW	43.1	24.82	14.37	1470	90	0.85	76	2.8	2.2	7	2.3	209
YBF2-200L-4	30kW	57.6	33.16	19.2	1470	92.5	0.86	79	2.8	2.2	7.2	2.4	289
YBF2-225S-4	37kW	69.9	40.25	23.3	1480	92.8	0.87	81	2.8	2.2	7.2	2.4	303
YBF2-225M-4	45kW	84.7	48.77	28.24	1480	92.8	0.87	81	2.8	2.2	7.2	2.4	278
YBF2-250M-4	55kW	102.7	59.13	34.23	1480	93	0.87	83	3.5	2.2	7.2	2.4	446
YBF2-280S-4	75kW	139.6	80.38	46.54	1480	93.8	0.87	86	3.5	2.2	7.2	2.4	635
YBF2-280M-4	90kW	166.9	96.09	55.63	1480	94.2	0.87	86	3.5	2.2	7.2	2.4	708
YBF2-315S-4	110kW	198.7	114.4	66.23	1485	94.5	0.89	93	3.5	2.1	7	2.4	998
YBF2-315M-4	132kW	237.7	136.86	79.23	1485	94.8	0.89	93	3.5	2.1	7	2.4	1035
YBF2-315L1-4	160kW	284.3	163.69	94.77	1485	95	0.9	97	3.5	2.1	7	2.4	1345
YBF2-315L2-4	200kW	354.7	204.22	118.23	1485	95.2	0.9	97	3.5	2.1	7	2.4	1600
YBF2-355S1-4	185kW	328.7	189.25	109.57	1485	95	0.9	97	3.5	2.1	7	2.4	1690
YBF2-355S2-4	200kW	354.7	204.22	118.23	1485	95.2	0.9	97	3.5	2.1	7	2.3	1690
YBF2-355M1-4	220kW	390.1	224.6	130.03	1485	95.2	0.9	101	3.5	2.1	7	2.4	1860
YBF2-355M2-4	250kW	442.9	255	147.63	1485	95.5	0.9	101	3.5	2.1	7	2.4	2100
YBF2-355L1-4	280kW	469	270.03	156.33	1485	95.5	0.9	101	3.5	2.1	7	2.4	2280
YBF2-355L2-4	315kW	556.2	320.24	185.4	1485	95.6	0.9	101	3.5	2.1	7	2.4	2280
YBF2-711-6	0.18kW	0.64	0.37	0.21	870	62	0.66	52	1.8	1.9	4	2.1	14
YBF2-712-6	0.25kW	0.83	0.48	0.28	870	63	0.68	52	1.8	1.9	4	2.1	15
YBF2-801-6	0.37kW	1.3	0.75	0.43	890	66	0.7	54	1.8	1.9	4	2.1	17
YBF2-802-6	0.55kW	1.7	0.98	0.57	890	66	0.72	54	1.8	1.9	4	2.1	19
YBF2-90S-6	0.75kW	2.3	1.32	0.76	910	69	0.72	57	1.8	2.1	5	2.1	21
YBF2-90L-6	1.1kW	3.1	1.78	1.03	910	73	0.73	57	1.8	2.1	5	2.1	23
YBF2-100L-6	1.5kW	3.9	2.25	1.3	930	76	0.76	61	1.8	2.1	5	2.1	32
YBF2-112M-6	2.2kW	5.6	3.22	1.86	940	79	0.76	65	1.8	2.1	5	2.1	36
YBF2-132S-6	3kW	7.3	4.2	2.43	970	81	0.77	69	1.8	2.1	6	2.4	42
YBF2-132M1-6	4kW	9.4	5.41	3.13	970	83	0.78	69	1.8	2.1	6	2.4	53
YBF2-132M2-6	5.5kW	12.6	7.25	4.2	970	85	0.78	69	1.8	2.1	6.5	2.4	78
YBF2-160M-6	7.5kW	16.8	9.67	5.6	970	86	0.79	73	2.8	2.1	6.5	2.4	112
YBF2-160L-6	11kW	24.3	13.99	8.1	970	87.5	0.79	73	2.8	2.1	6.5	2.4	133
YBF2-180L-6	15kW	31.6	18.19	10.53	980	89	0.81	73	2.8	2.1	7	2.1	148
YBF2-200L1-6	18.5kW	37.6	21.65	12.53	980	90	0.83	76	2.8	2.2	7	2.4	185
YBF2-200L2-6	22kW	44.7	25.74	14.9	980	90	0.83	76	2.8	2.2	7	2.4	215
YBF2-225M-6	30kW	57.6	33.16	19.2	980	92	0.86	76	2.8	2.1	7	2.4	289
YBF2-250M-6	37kW	69.8	40.19	23.27	980	92	0.86	78	3.5	2.1	7	2.4	461
YBF2-280S-6	45kW	85.9	49.46	28.63	990	92.5	0.86	80	3.5	2.1	7	2.4	530
YBF2-280M-6	55kW	104.7	60.28	34.9	990	92.8	0.86	80	3.5	2.1	7	2.3	600
YBF2-315S-6	75kW	141.7	81.58	47.23	989	93.5	0.86	85	3.5	2	7	2.2	985
YBF2-315M-6	90kW	169.5	97.59	56.5	989	93.8	0.87	85	3.5	2	7	2.2	1080
YBF2-315L1-6	110kW	206.7	119.01	68.9	989	94	0.89	85	3.5	2	7	2.2	1150
YBF2-315L2-6	132kW	244.7	140.89	81.57	989	94.2	0.89	85	3.5	2	7	2.2	1200
YBF2-355S-6	160kW	292.3	168.29	97.43	989	94.5	0.9	92	3.5	2	7	2.2	1620
YBF2-355M1-6	185kW	338	194.61	112.67	989	94.5	0.9	92	3.5	2	7	2.2	1730
YBF2-355M2-6	200kW	364.6	209.92	121.53	989	94.7	0.9	92	3.5	2	7	2.2	1930
YBF2-355L1-6	220kW	401.1	230.94	133.7	989	94.7	0.9	92	3.5	2	7	2.2	2120
YBF2-355L2-6	250kW	454.3	261.57	151.44	989	95	0.9	95	3.5	2	7	2.2	2230
YBF2-801-8	0.18kW	0.8	0.46	0.27	650	52	0.61	52	1.8	1.8	3.3	1.9	17
YBF2-802-8	0.25kW	1.1	0.63	0.36	650	55	0.61	52	1.8	1.8	3.3	1.9	19
YBF2-90S-8	0.37kW	1.4	0.81	0.47	670	63	0.62	56	1.8	1.8	4	2	23
YBF2-90L-8	0.55kW	2.1	1.21	0.7	670	64	0.63	56	1.8	1.8	4	2	25
YBF2-100L1-8	0.75kW	2.4	1.38	0.8	690	71	0.68	59	1.8	1.8	4	2	33
YBF2-100L2-8	1.1kW	3.3	1.9	1.1	690	73	0.69	59	1.8	1.8	4	2	38
YBF2-112M-8	1.5kW	4.4	2.53	1.46	690	75	0.69	61	1.8	1.8	4	2	50
YBF2-132S-8	2.2kW	5.6	3.22	1.86	710	79	0.73	64	1.8	1.8	5.5	2.2	63
YBF2-132M-8	3kW	7.6	4.38	2.54	720	81	0.73	64	1.8	1.8	5.5	2.2	80
YBF2-160M1-8	4kW	10.3	5.93	3.43	720	81	0.73	68	2.8	1.9	6	2.2	120
YBF2-160M2-8	5.5kW	13.4	7.72	4.47	720	83	0.75	68	2.8	1.9	6	2.2	142
YBF2-160L-8	7.5kW	17.5	10.08	5.84	720	85	0.76	68	2.8	1.9	6	2.2	165
YBF2-180L-8	11kW	25.3	14.57	8.44	720	87	0.76	70	2.8	1.9	6	2.2	212
YBF2-200L-8	15kW	33.7	19.4	11.23	730	89	0.76	73	2.8	2	6.5	2.2	288
YBF2-225S-8	18.5kW	40	23.03	13.33	740	90	0.78	73	2.8	2	6.5	2.2	336
YBF2-225M-8	22kW	47.4	27.29	15.8	740	90.5	0.78	73	2.8	2	6.5	2.2	365
YBF2-250M-8	30kW	63.4	36.5	21.13	740	91	0.79	75	3.5	1.9	6.5	2	510
YBF2-280S-8	37kW	77.8	44.79	25.93	740	91.5	0.79	76	3.5	1.8	6	2	625
YBF2-280M-8	45kW	94.1	54.18	31.37	740	92	0.79	82	3.5	1.8	6	2	710
YBF2-315S-8	55kW	111.2	64.02	37.06	741	92.8	0.81	82	3.5	1.9	6.5	2.2	960
YBF2-315M-8	75kW	151.3	87.11	50.43	741	93	0.81	82	3.5	1.9	6.5	2.2	1050
YBF2-315L1-8	90kW	177.8	102.37	59.27	741	93.8	0.82	82	3.5	1.9	6.5	2.2	1220
YBF2-315L2-8	110kW	216.8	124.82	72.26	741	94	0.82	82	3.5	2	6.5	2.2	1380
YBF2-355S-8	132kW	259.6	149.47	86.54	742	94.2	0.82	90	3.5	2	6.5	2.2	1690
YBF2-355M-8	160kW	313.4	180.44	104.47	742	94.6	0.82	90	3.5	2	6.5	2.2	1830
YBF2-355L1-8	185kW	362.3	208.6	120.77	742	94.6	0.82	90	3.5	2	6.5	2.2	2200
YBF2-355L2-8	200kW	386.2	222.36	128.73	742	94.8	0.83	90	3.5	2	6.5	2.2	2250
YBF2-315S-10	45kW	99.1	57.06	33.03	596	92	0.75	82	3.5	1.5	6	2.1	1020
YBF2-315M-10	55kW	121.1	69.72	40.36	596	92	0.75	82	3.5	1.5	6	2.1	1060
YBF2-315L1-10	75kW	162.1	93.33	54.03	596	92.5	0.76	82	3.5	1.5	6	2.1	1210
YBF2-315L2-10	90kW	191	109.97	63.67	596	93	0.77	82	3.5	1.5	6	2.1	1380
YBF2-355S-10	90kW	190.8	109.85	63.6	597	93	0.77	82	3.5	1.5	6	2.1	1650
YBF2-355M1-10	110kW	230.4	132.65	76.8	597	93.2	0.78	90	3.5	1.3	5.5	2.1	1790
YBF2-355M2-10	132kW	275	158.33	91.66	597	93.5	0.78	90	3.5	1.3	5.5	2.1	1820
YBF2-355L1-10	160kW	333	191.73	111	597	93.6	0.78	90	3.5	1.3	5.5	2.1	2100
YBF2-355L2-10	185kW	385	221.67	128.34	597	93.6	0.78	90	3.5	1.3	5.5	2.1	2250
