Description
YTS Series(IP23) Variable-Frequency Adjustable-Speed Three-phase Induction Motors for Hoist Applications
| Type |
Rated power kW |
Rated Current A |
Rated output torque |
Rated Speed r/min |
Locked Torque/ Rated Torque |
Max.Torque/ Rated Torque |
Moment of inertia kg.m² |
Weight kg |
|---|---|---|---|---|---|---|---|---|
| YTS-200M-4 | 37 | 71 | 240 | 1470 | 2 | 2.8 | 1 | 385 |
| YTS-200L-4 | 45 | 86 | 292 | 1470 | 2 | 2.8 | 1.2 | 405 |
| YTS-225M-4 | 55 | 104 | 357 | 1470 | 2 | 2.8 | 1.5 | 450 |
| YTS-250S-4 | 75 | 133 | 483 | 1482 | 2 | 2.8 | 1.4 | 475 |
| YTS-250M-4 | 90 | 158 | 580 | 1481 | 2 | 2.8 | 1.5 | 520 |
| YTS-280S-4 | 110 | 204 | 711 | 1478 | 2 | 2.8 | 1.9 | 640 |
| YTS-280M-4 | 132 | 243 | 852 | 1480 | 2 | 2.8 | 2.2 | 710 |
| YTS-315S-4 | 160 | 295 | 1032 | 1480 | 2 | 2.8 | 3.3 | 910 |
| YTS-315M1-4 | 185 | 339 | 1192 | 1482 | 2.2 | 3.2 | 3.6 | 1020 |
| YTS-315M2-4 | 200 | 365 | 1289 | 1482 | 2.2 | 3.2 | 3.9 | 1100 |
| YTS-315M3-4 | 220 | 401 | 1418 | 1483 | 2.2 | 3.2 | 4.2 | 1230 |
| YTS-355M1-4 | 250 | 427 | 1605 | 1487 | 2.2 | 3.2 | 8.8 | 1180 |
| YTS-355M2-4 | 280 | 478 | 1798 | 1487 | 2.2 | 3.2 | 9.6 | 1300 |
| YTS-355M3-4 | 315 | 536 | 2022 | 1488 | 1.6 | 2.8 | 10.8 | 1370 |
| YTS-355L1-4 | 355 | 601 | 2280 | 1487 | 1.6 | 2.8 | 12.4 | 1580 |
| YTS-355L2-4 | 400 | 676 | 2568 | 1487 | 1.6 | 2.8 | 14.1 | 1620 |
| YTS-400S3-4 | 400 | 687 | 2569 | 1487 | 1.6 | 2.8 | 16.7 | 2310 |
| YTS-400L1-4 | 450 | 769 | 2890 | 1487 | 1.6 | 2.8 | 17.5 | 2490 |
| YTS-400L2-4 | 500 | 853 | 3211 | 1487 | 2 | 3 | 19.4 | 2580 |
| YTS-400L3-4 | 560 | 952 | 3601 | 1485 | 2 | 3 | 23.8 | 2630 |
| YTS-400L4-4 | 630 | 1066 | 4049 | 1486 | 2 | 3 | 29 | 2660 |
| YTS-200M-6 | 22 | 44 | 435 | 971 | 2 | 2.4 | 1.4 | 440 |
| YTS-200L-6 | 30 | 60 | 295 | 972 | 2 | 2.4 | 1.5 | 440 |
| YTS-225M-6 | 37 | 68 | 353 | 981 | 2 | 2.4 | 2 | 400 |
| YTS-250S-6 | 45 | 82 | 435 | 987 | 2 | 2.4 | 1.7 | 440 |
| YTS-250M-6 | 55 | 100 | 532 | 987 | 2 | 2.4 | 2 | 480 |
| YTS-250M2-6 | 75 | 135 | 728 | 983 | 2 | 2.4 | 2.1 | 605 |
| YTS-280S-6 | 75 | 142 | 727 | 985 | 2 | 3 | 2.4 | 620 |
| YTS-280M-6 | 90 | 168 | 873 | 985 | 2 | 3 | 3.1 | 740 |
| YTS-315S-6 | 110 | 205 | 1063 | 988 | 2 | 3 | 3.9 | 915 |
| YTS-315M1-6 | 132 | 245 | 1276 | 988 | 2 | 3 | 4.6 | 1090 |
| YTS-315M2-6 | 160 | 296 | 1543 | 990 | 2 | 3 | 5.5 | 1200 |
| YTS-355M1-6 | 185 | 324 | 1785 | 990 | 2 | 2.8 | 9.3 | 1495 |
| YTS-355M2-6 | 200 | 350 | 1929 | 990 | 2 | 2.8 | 10.2 | 1575 |
| YTS-355M3-6 | 220 | 383 | 2123 | 990 | 2 | 2.8 | 11.4 | 1610 |
| YTS-355M4-6 | 250 | 434 | 2413 | 989 | 2 | 2.8 | 13.1 | 1760 |
| YTS-355L1-6 | 280 | 485 | 2703 | 989 | 2 | 2.8 | 15 | 1780 |
| YTS-355L2-6 | 315 | 547 | 3040 | 989 | 2 | 2.8 | 16.4 | 1800 |
| YTS-400S1-6 | 315 | 548 | 3036 | 991 | 1.7 | 2.6 | 21.4 | 2190 |
| YTS-400S2-6 | 355 | 617 | 3421 | 991 | 1.7 | 2.6 | 23.4 | 2260 |
| YTS-400S3-6 | 400 | 694 | 3855 | 991 | 1.7 | 2.6 | 28.5 | 2340 |
| YTS-400L1-6 | 450 | 780 | 4337 | 991 | 1.7 | 2.6 | 29.7 | 2570 |
| YTS-400L2-6 | 500 | 865 | 4818 | 991 | 1.7 | 2.6 | 33.1 | 2600 |
| YTS-400L3-6 | 560 | 966 | 5402 | 990 | 1.7 | 2.6 | 37.1 | 2660 |
| YTS-400L4-6 | 630 | 1058 | 6071 | 991 | 1.7 | 2.6 | 40 | 2720 |
| YTS-200M-8 | 18.5 | 41 | 244 | 725 | 1.8 | 2.4 | 1.2 | 395 |
| YTS-200L-8 | 22 | 48 | 290 | 725 | 1.8 | 2.4 | 1.3 | 405 |
| YTS-225M-8 | 30 | 63 | 395 | 725 | 1.8 | 2.4 | 1.5 | 420 |
| YTS-250S-8 | 37 | 72 | 479 | 738 | 1.8 | 2.4 | 1.7 | 435 |
| YTS-250M-8 | 45 | 87 | 582 | 738 | 1.8 | 2.4 | 2 | 480 |
| YTS-250M2-8 | 55 | 105 | 714 | 736 | 1.8 | 2.4 | 3.1 | 520 |
| YTS-280S-8 | 55 | 111 | 717 | 733 | 2 | 2.8 | 2.4 | 625 |
| YTS-280M-8 | 75 | 151 | 977 | 733 | 2 | 2.8 | 3.1 | 740 |
| YTS-315S-8 | 90 | 182 | 1169 | 735 | 2 | 2.8 | 5.9 | 895 |
| YTS-315M1-8 | 110 | 221 | 1429 | 735 | 2 | 2.8 | 6.8 | 1060 |
| YTS-315M2-8 | 132 | 263 | 1715 | 735 | 2 | 2.8 | 7.8 | 1170 |
| YTS-355M2-8 | 160 | 304 | 2064 | 740 | 2.2 | 2.8 | 10.7 | 1585 |
| YTS-355M3-8 | 185 | 349 | 2388 | 740 | 2.2 | 2.8 | 12.5 | 1685 |
| YTS-355M4-8 | 200 | 380 | 2579 | 740 | 2.2 | 2.8 | 14 | 1768 |
| YTS-355L1-8 | 220 | 416 | 2837 | 740 | 2.2 | 2.8 | 15 | 1945 |
| YTS-355L2-8 | 250 | 471 | 3226 | 740 | 2.2 | 2.8 | 15.8 | 1990 |
| YTS-355L3-8 | 260 | 487 | 3356 | 740 | 2.2 | 2.8 | 17.6 | 2050 |
| YTS-355L4-8 | 280 | 526 | 3614 | 740 | 2.2 | 2.8 | 17.6 | 2010 |
| YTS-400S1-8 | 280 | 514 | 4045 | 741 | 1.7 | 2.6 | 22.5 | 2210 |
| YTS-400S2-8 | 315 | 576 | 4565 | 740 | 1.7 | 2.6 | 27.4 | 2290 |
| YTS-400S3-8 | 355 | 650 | 4575 | 741 | 1.7 | 2.6 | 30.8 | 2440 |
| YTS-400L1-8 | 400 | 730 | 5155 | 741 | 1.7 | 2.6 | 34.8 | 2650 |
| YTS-400L2-8 | 450 | 820 | 5800 | 741 | 1.7 | 2.6 | 34.8 | 2800 |
| YTS-400L3-8 | 500 | 915 | 6444 | 741 | 1.7 | 2.6 | 38.8 | 2820 |
| YTS-400L4-8 | 560 | 1022 | 7217 | 741 | 1.7 | 2.6 | 40 | 2870 |
| YTS-315S-10 | 55 | 110 | 886 | 593 | 1.8 | 2.8 | 5.2 | 790 |
| YTS-315M1-10 | 75 | 147 | 1209 | 592 | 1.8 | 2.8 | 6.4 | 1050 |
| YTS-315M2-10 | 90 | 176 | 1451 | 592 | 1.8 | 2.8 | 7.5 | 1110 |
| YTS-355M2-10 | 110 | 214 | 1773 | 592 | 1.9 | 2.8 | 11.9 | 1510 |
| YTS-355M3-10 | 132 | 255 | 2128 | 592 | 1.9 | 2.8 | 14.7 | 1610 |
| YTS-355L1-10 | 160 | 306 | 2582 | 592 | 1.9 | 2.8 | 16.6 | 1890 |
| YTS-355L2-10 | 185 | 355 | 2982 | 593 | 1.9 | 2.8 | 19.2 | 2080 |
| YTS-355L3-10 | 200 | 384 | 3225 | 592 | 1.9 | 2.8 | 20.6 | 2120 |
| YTS-400S1-10 | 200 | 375 | 3226 | 592 | 1.5 | 2.5 | 22.8 | 2170 |
| YTS-400S2-10 | 220 | 410 | 3549 | 592 | 1.5 | 2.5 | 25.1 | 2250 |
| YTS-400S3-10 | 250 | 466 | 4033 | 592 | 1.5 | 2.5 | 27.4 | 2340 |
| YTS-400S4-10 | 280 | 522 | 4517 | 592 | 1.5 | 2.5 | 32 | 2430 |
| YTS-400L1-10 | 315 | 586 | 5215 | 592 | 1.5 | 2.5 | 36 | 2630 |
| YTS-400L2-10 | 355 | 660 | 5727 | 592 | 1.5 | 2.5 | 37.7 | 2760 |
| YTS-400L3-10 | 400 | 743 | 6453 | 592 | 1.5 | 2.5 | 42.3 | 2870 |
| YTS-355M4-12 | 90 | 191 | 1742 | 493 | 1.4 | 2.5 | 13.2 | 1615 |
| YTS-355L1-12 | 110 | 230 | 2131 | 493 | 1.4 | 2.5 | 15.6 | 1630 |
| YTS-355L2-12 | 132 | 275 | 2559 | 493 | 1.4 | 2.5 | 17.6 | 1870 |
| YTS-355L3-12 | 160 | 331 | 3103 | 492 | 1.4 | 2.5 | 20.6 | 1930 |
| YTS-400S1-12 | 160 | 325 | 2552 | 494 | 1.5 | 2.5 | 25.1 | 2230 |
| YTS-400S2-12 | 185 | 371 | 3093 | 494 | 1.5 | 2.5 | 27.4 | 2320 |
| YTS-400S3-12 | 200 | 404 | 3576 | 494 | 1.5 | 2.5 | 32 | 2390 |
| YTS-400L1-12 | 220 | 441 | 3866 | 494 | 1.5 | 2.5 | 36 | 2600 |
| YTS-400L2-12 | 250 | 504 | 4253 | 494 | 1.5 | 2.5 | 37.7 | 2750 |
| YTS-400L3-12 | 280 | 561 | 4833 | 494 | 1.5 | 2.5 | 42.3 | 2840 |
