YR Series (IP23) Wound Rotor Three-Phase Induction Motor

Description

Filterable Table with Fixed Header

型号	型号	功率(KW)	转速(r/min)	电流	效率(η%)	功率因数cosφ	最大转矩/额定转矩	转子电压	转子电流	噪音	转动惯量	重量kg
4级4 pole	160M-4	7.5	1421	16	84	0.84	2.8	260	19	85	0.395	150
4级4 pole	160L1-4	11	1434	22.6	86.5	0.85	2.8	275	26	85	0.486	160
4级4 pole	160L2-4	15	1444	30.2	87	0.85	2.8	260	37	88	0.597	165
4级4 pole	180M-4	18.5	1426	36.1	87	0.88	2.8	197	61	88	1	220
4级4 pole	180L-4	22	1434	42.5	88	0.88	3	232	61	88	1.09	250
4级4 pole	200M-4	30	1439	57.7	89	0.88	3	255	76	91	1.82	280
4级4 pole	200L-4	37	1448	70.2	89	0.88	3	316	74	91	2.21	329
4级4 pole	225M1-4	45	1442	86.7	89	0.88	2.5	240	120	94	0.6	370
4级4 pole	225M2-4	55	1448	104.7	90	0.88	2.5	288	121	94	2.96	400
4级4 pole	250S-4	75	1453	141.1	90.5	0.89	2.6	449	105	97	5.35	460
4级4 pole	250M-4	90	1457	167.9	91	0.89	2.6	524	107	97	6	550
4级4 pole	280S-4	110	1458	201.3	91.5	0.89	3	349	196	100	9.1	680
4级4 pole	280M-4	132	1463	239	92.5	0.89	3	419	194	100	10.39	750
4级4 pole	315S-4	160	1468	290	92.5	0.87	1.8	340	288.8	103	-	935
4级4 pole	315M1-4	185	1469	331	92.8	0.87	1.8	383	296.2	103	-	935
4级4 pole	315M2-4	200	1473	359	93.3	0.87	1.8	438	278.3	103	-	985
4级4 pole	315M3-4	220	1474	395	93.3	0.87	1.8	472	284	103	-	985
6级6 pole	160M-6	5.5	949	12.7	82.5	0.77	2.5	279	13	78	0.572	145
6级6 pole	160L-6	7.5	949	16.9	83.5	0.78	2.5	260	19	82	0.655	160
6级6 pole	180M-6	11	940	24.2	84.5	0.78	2.8	146	50	82	6.25	220
6级6 pole	180L-6	15	947	32.6	85.5	0.79	2.8	187	53	85	1.48	240
6级6 pole	200M-6	18.5	949	39	86.5	0.81	2.8	187	65	5	2.17	292
6级6 pole	200L-6	22	955	45.5	87.5	0.82	2.8	224	63	85	2.55	318
6级6 pole	225M1-6	30	955	59.4	87.5	0.85	2.2	227	86	88	3.237	360
6级6 pole	225M2-6	37	964	73.1	89	0.85	2.2	287	82	88	3.736	400
6级6 pole	250S-6	45	966	88	89	0.85	2.2	307	93	91	6.61	465
6级6 pole	250M-6	55	967	105.7	89.5	0.86	2.2	359	97	91	7.52	490
6级6 pole	280S-6	75	969	141.8	90.5	0.88	2.5	392	121	94	11.52	660
6级6 pole	280M-6	90	972	166.7	91	0.89	2.5	481	118	94	14.05	780
6级6 pole	315S-6	110	976	208	92.5	0.86	1.8	253	270	97	-	920
6级6 pole	315M1-6	132	979	249	92.8	0.86	1.8	307	265	100	-	950
6级6 pole	315M2-6	160	981	301	93.3	0.86	1.8	374	262	100	-	115
8级8 pole	160M-8	4	703	10.5	81	0.71	2.2	262	11	77	0.567	144
8级8 pole	160L-8	5.5	705	14.2	81.5	0.71	2.2	243	15	77	0.648	160
8级8 pole	180M-8	7.5	692	18.4	82	0.73	2.2	105	49	81	1.236	225
8级8 pole	180L-8	11	699	26.8	83	0.73	2.2	140	53	81	1.47	240
8级8 pole	200M-8	15	706	36.1	85	0.73	2.2	153	64	84	2.142	285
8级8 pole	200L-8	18.5	712	44	86	0.73	2.2	187	64	84	2.52	323
8级8 pole	225M1-8	22	710	48.6	86	0.78	2	161	90	84	3.164	350
8级8 pole	225M2-8	30	713	65.3	87	0.79	2	200	97	87	3.621	390
8级8 pole	250S-8	37	715	78.9	87.5	0.79	2	218	110	87	6.42	442
8级8 pole	250M-8	45	720	95.5	88.5	0.79	2	264	109	90	7.33	465
8级8 pole	280S-8	55	723	114	89	0.82	2.2	279	125	90	10.55	666
8级8 pole	280M-8	75	725	152.1	90	0.82	2.2	359	131	93	13.71	780
8级8 pole	315S-8	90	718	180	92	0.79	1.8	406	139	93	-	930
8级8 pole	315M1-8	110	733	219.5	92.5	0.79	1.8	473	145	93	-	990
8级8 pole	315M2-8	132	734	262	92.8	0.79	1.8	284	289	97	-	1065
10级10 pole	315S-10	55	577	118.5	90	0.74	1.8	263	131	93	-	920
10级10 pole	315M1-10	75	580	160	91	0.74	1.8	351	132	93	-	920
10级10 pole	315M2-10	90	582	191	91.5	0.75	1.8	421	132	93	-	920
