YBX3 Series Flameproof Three-Phase Asynchronous Motor

Description

Spefication of YBX3 Series Flameproof Three-Phase Asynchronous Motor

Frame size	Output (kW)	Current (A)	Speed (r/min)	Efficency %	Power Factor COSØ	Noise dB(A)	kg.m2	Locked Torque /Rated Torque	Locked Current /Rated Current	Pull-out Torque /Rated Torque	Weight (kg)
YBX3-63M1-2	0.18kW	0.52	2720	66	0.8	61	0.0021	2.2	5	2.3	14
YBX3-63M2-2	0.25kW	0.69	2720	68	0.81	61	0.0028	2.2	5	2.3	15
YBX3-71M1-2	0.37kW	0.99	2740	70	0.81	64	0.0033	2.2	5.5	2.3	17
YBX3-71M2-2	0.55kW	1.36	2740	74	0.83	64	0.0035	2.3	5.5	2.3	18
YBX3-80M1-2	0.75kW	1.72	2895	80.7	0.82	67	0.0049	2.3	7	2.3	26
YBX3-80M2-2	1.1kW	2.44	2890	82.7	0.83	67	0.0059	2.2	7.3	2.3	30
YBX3-90S-2	1.5kW	3.22	2898	84.2	0.84	72	0.0095	2.2	7.6	2.3	36
YBX3-90L-2	2.2kW	4.58	2898	85.9	0.85	72	0.012	2.2	7.6	2.3	39
YBX3-100L-2	3kW	6.02	2895	87.1	0.87	76	0.0208	2.2	7.8	2.3	50
YBX3-112M-2	4kW	7.84	2913	88.1	0.88	77	0.037	2.2	8.3	2.3	63
YBX3-132S1-2	5.5kW	10.6	2945	89.2	0.88	80	0.0736	2	8.3	2.3	88
YBX3-132S2-2	7.5kW	14.4	2940	90.1	0.88	80	0.0908	2	7.9	2.3	92
YBX3-160M1-2	11kW	20.6	2950	91.2	0.89	86	0.241	2	8.1	2.3	143
YBX3-160M2-2	15kW	27.9	2950	91.9	0.89	86	0.301	2	8.1	2.3	153
YBX3-160L-2	18.5kW	34.2	2950	92.4	0.89	86	0.351	2	8.2	2.3	174
YBX3-180M-2	22kW	40.5	2960	92.7	0.89	88	0.477	2	8.2	2.3	230
YBX3-200L1-2	30kW	54.9	2970	93.3	0.89	90	0.767	2	7.6	2.3	296
YBX3-200L2-2	37kW	67.4	2970	93.7	0.89	90	0.85	2	7.6	2.3	326
YBX3-225M-2	45kW	80.8	2975	94	0.9	92	1.424	2	7.7	2.3	424
YBX3-250M-2	55kW	98.5	2980	94.3	0.9	93	1.75	2	7.7	2.3	527
YBX3-280S-2	75kW	133.7	2980	94.7	0.9	94	1.89	1.8	7.1	2.3	670
YBX3-280M-2	90kW	160	2980	95	0.9	94	2.02	1.8	7.1	2.3	718
YBX3-315S-2	110kW	195.1	2980	95.2	0.9	96	2.22	1.8	7.1	2.3	1078
YBX3-315M-2	132kW	233.6	2980	95.4	0.9	96	2.37	1.8	7.1	2.3	1157
YBX3-315L1-2	160kW	279.4	2980	95.6	0.91	98	3.08	1.8	7.2	2.3	1242
YBX3-315L2-2	200kW	348.6	2980	95.8	0.91	98	3.52	1.8	7.2	2.2	1298
YBX3-355S1-2	185kW	322.8	2985	95.7	0.91	98	3.33	1.8	7.2	2.2	1640
YBX3-355S2-2	200kW	348.6	2985	95.8	0.91	98	4.79	1.8	7.2	2.2	1640
YBX3-355M1-2	220kW	383.4	2985	95.8	0.91	100	4.79	1.6	7.2	2.2	1850
YBX3-355M2-2	250kW	435.7	2985	95.8	0.91	100	4.79	1.6	7.2	2.2	1900
YBX3-355L1-2	280kW	488	2985	95.8	0.91	100	5.66	1.6	7.2	2.2	2010
YBX3-355L2-2	315kW	549	2985	95.8	0.91	100	6.53	1.6	7.2	2.2	2140
YBX3-355L3-2	355kW	618.7	2985	95.8	0.91	103	6.83	1.6	7.2	2.2	2550
YBX3-63M1-4	0.12kW	0.44	1310	58	0.72	52	0.0033	2.3	4	2.2	14
YBX3-63M2-4	0.18kW	0.59	1310	63	0.73	52	0.0035	2.3	4	2.2	15
YBX3-71M1-4	0.25kW	0.78	1330	66	0.74	55	0.0042	2.3	4	2.2	16
YBX3-71M2-4	0.37kW	1.09	1330	69	0.75	55	0.005	2.3	4	2.2	17
YBX3-80M1-4	0.55kW	1.38	1440	80.7	0.75	58	0.0085	2.3	6.3	2.2	26
YBX3-80M2-4	0.75kW	1.84	1437	82.5	0.75	58	0.0116	2.3	6.6	2.3	29
YBX3-90S-4	1.1kW	2.61	1440	84.1	0.76	61	0.0189	2.3	6.8	2.3	34
YBX3-90L-4	1.5kW	3.47	1440	85.3	0.77	61	0.0225	2.3	7	2.3	39
YBX3-100L1-4	2.2kW	4.76	1455	86.7	0.81	64	0.045	2.3	7.6	2.3	47
YBX3-100L2-4	3kW	6.34	1455	87.7	0.82	64	0.053	2.3	7.6	2.3	52
YBX3-112M-4	4kW	8.37	1460	88.6	0.82	65	0.084	2.2	7.8	2.3	67
YBX3-132S-4	5.5kW	11.2	1470	89.6	0.83	71	0.151	2	7.9	2.3	88
YBX3-132M-4	7.5kW	15	1470	90.4	0.84	71	0.213	2	7.5	2.3	101
YBX3-160M-4	11kW	21.5	1475	91.4	0.85	75	0.469	2.2	7.7	2.3	147
YBX3-160L-4	15kW	28.8	1475	92.1	0.86	75	0.562	2.2	7.8	2.3	172
YBX3-180M-4	18.5kW	35.3	1480	92.6	0.86	76	0.831	2	7.8	2.3	236
YBX3-180L-4	22kW	41.8	1480	93	0.86	76	1.03	2	7.8	2.3	252
YBX3-200L-4	30kW	56.6	1480	93.6	0.86	79	1.12	2	7.3	2.3	320
YBX3-225S-4	37kW	69.6	1485	93.9	0.86	81	1.21	2	7.4	2.3	402
YBX3-225M-4	45kW	84.4	1485	94.2	0.86	81	1.85	2	7.4	2.3	442
YBX3-250M-4	55kW	102.7	1485	94.6	0.86	83	2.32	2.2	7.4	2.3	544
YBX3-280S-4	75kW	136.3	1488	95	0.88	86	2.86	2	6.9	2.3	714
YBX3-280M-4	90kW	163.2	1488	95.2	0.88	86	3.34	2	7.9	2.3	794
YBX3-315S-4	110kW	199.1	1488	95.4	0.89	93	4.68	2	7	2.2	1122
YBX3-315M-4	132kW	238.9	1488	95.6	0.89	93	4.96	2	7	2.2	1221
YBX3-315L1-4	160kW	285.1	1488	95.8	0.89	94	5.22	2	7.1	2.2	1298
YBX3-315L2-4	200kW	351.7	1488	96	0.9	94	5.51	2	7.1	2.2	1408
YBX3-355S1-4	185kW	329.3	1490	95.9	0.89	94	5.9	2	7.1	2.2	1650
YBX3-355S2-4	200kW	351.7	1490	96	0.9	94	6.9	2	7.1	2.2	1680
YBX3-355M1-4	220kW	386.9	1490	96	0.9	95	8.8	2	7.1	2.2	1870
YBX3-355M2-4	250kW	439.6	1490	96	0.9	95	9.72	2	7.1	2.2	1870
YBX3-355L1-4	280kW	492.4	1490	96	0.9	95	10.64	2	7.1	2.2	2050
YBX3-355L2-4	315kW	553.9	1490	96	0.9	95	12.11	2	7.1	2.2	2050
YBX3-355L3-4	355kW	638.5	1490	96	0.88	95	12.5	1.7	7	2.2	2350
YBX3-71M1-6	0.18kW	0.67	850	62	0.66	52	0.007	1.9	4	2.1	17
YBX3-71M2-6	0.25kW	0.89	850	63	0.68	52	0.0085	1.9	4	2.1	18
YBX3-80M1-6	0.37kW	1.27	885	63	0.7	54	0.0092	1.9	4	2.1	25
YBX3-80M2-6	0.55kW	1.54	885	75.4	0.72	54	0.012	1.9	4	2.1	27
YBX3-90S-6	0.75kW	2.03	958	78.9	0.71	57	0.023	2	6	2.1	34
YBX3-90L-6	1.1kW	2.83	958	81	0.73	57	0.028	2	6	2.1	38
YBX3-100L-6	1.5kW	3.78	957	82.5	0.73	61	0.055	2	6.5	2.1	47
YBX3-112M-6	2.2kW	5.36	969	84.3	0.74	65	0.093	2	6.6	2.1	63
YBX3-132S-6	3kW	7.2	975	85.6	0.74	69	0.199	2	6.8	2.1	84
YBX3-132M1-6	4kW	9.5	975	86.8	0.74	69	0.247	2	6.8	2.1	94
YBX3-132M2-6	5.5kW	12.7	975	88	0.75	69	0.308	2	7	2.1	102
YBX3-160M-6	7.5kW	16.2	980	89.1	0.79	73	0.318	2	7	2.1	142
YBX3-160L-6	11kW	23.1	980	90.3	0.8	73	0.742	2	7.2	2.1	169
YBX3-180L-6	15kW	30.9	980	91.2	0.81	73	1.28	2	7.3	2.1	240
YBX3-200L1-6	18.5kW	37.8	985	91.7	0.81	76	1.9	2	7.3	2.1	298
YBX3-200L2-6	22kW	44.8	985	92.2	0.81	76	2.24	2	7.4	2.1	308
YBX3-225M-6	30kW	59.1	988	92.9	0.83	76	2.89	2	6.9	2.1	416
YBX3-250M-6	37kW	71.7	990	93.3	0.84	78	3.36	2	7.1	2.1	511
YBX3-280S-6	45kW	85.8	990	93.7	0.85	80	3.46	2	7.3	2	660
YBX3-280M-6	55kW	103.3	990	94.1	0.86	80	3.97	2	7.3	2	718
YBX3-315S-6	75kW	143.4	990	94.6	0.84	85	4.25	2	6.6	2	1045
YBX3-315M-6	90kW	171.5	990	94.9	0.85	85	4.37	2	6.7	2	1167
YBX3-315L1-6	110kW	206.8	990	95.1	0.85	85	5.2	2	6.7	2	1265
YBX3-315L2-6	132kW	244.4	990	95.4	0.86	85	6.16	2	6.7	2	1342
YBX3-355S-6	160kW	295.7	990	95.6	0.86	92	11.37	1.8	6.8	2	1800
YBX3-355M1-6	185kW	341.5	990	95.7	0.87	92	11.37	1.8	6.8	2	1980
YBX3-355M2-6	200kW	364.6	990	95.8	0.87	92	13.75	1.8	6.8	2	2040
YBX3-355L1-6	220kW	401	990	95.8	0.87	92	15.67	1.8	6.8	2	2150
YBX3-355L2-6	250kW	455.7	990	95.8	0.87	92	16.33	1.8	6.8	2	2200
YBX3-355L3-6	280kW	516.4	990	95.8	0.86	92	16.62	1.8	6.8	2	2380
YBX3-80M1-8	0.18kW	0.86	645	52	0.61	52	0.039	1.8	3.3	1.9	26
YBX3-80M2-8	0.25kW	1.13	645	55	0.61	52	0.047	1.8	3.3	1.9	27
YBX3-90S-8	0.37kW	1.44	670	63	0.62	56	0.059	1.8	4	1.9	32
YBX3-90L-8	0.55kW	2.07	670	64	0.63	56	0.061	1.8	4	2	35
YBX3-100L1-8	0.75kW	2.36	680	71	0.68	59	0.077	1.8	4	2	41
YBX3-100L2-8	1.1kW	3.32	680	73	0.69	59	0.083	1.8	5	2	43
YBX3-112M-8	1.5kW	4.4	690	75	0.69	61	0.095	1.8	5	2	56
YBX3-132S-8	2.2kW	5.8	705	79	0.73	64	0.12	1.8	6	2	76
YBX3-132M-8	3kW	7.7	705	81	0.73	64	0.2	1.8	6	2	85
YBX3-160M1-8	4kW	10.3	720	81	0.73	68	0.36	1.9	6	2	116
YBX3-160M2-8	5.5kW	13.4	720	83	0.75	68	0.46	1.9	6	2	127
YBX3-160L-8	7.5kW	17.6	720	85	0.76	68	0.61	1.9	6	2	151
YBX3-180L-8	11kW	25.3	730	87	0.76	70	1.06	2	6.5	2	198
YBX3-200L-8	15kW	33.7	730	89	0.76	73	1.6	2	6.6	2	256
YBX3-225S-8	18.5kW	40.1	730	90	0.78	73	2.28	1.9	6.6	2	322
YBX3-225M-8	22kW	47.4	730	90.5	0.78	73	2.74	1.9	6.6	2	349
YBX3-250M-8	30kW	63.4	735	91	0.79	75	2.91	1.9	6.5	2	431
YBX3-280S-8	37kW	77.8	735	91.5	0.79	76	3.21	1.9	6.6	2	556
YBX3-280M-8	45kW	94.1	735	92	0.79	76	3.42	1.9	6.6	2	613
YBX3-315S-8	55kW	111.2	740	92.8	0.81	82	3.72	1.8	6.6	2	930
YBX3-315M-8	75kW	150	740	93.5	0.81	82	4.15	1.8	6.2	2	1090
YBX3-315L1-8	90kW	177.8	740	93.8	0.82	82	4.8	1.8	6.4	2	1180
YBX3-315L2-8	110kW	216.8	740	94	0.82	82	5.44	1.8	6.4	2	1270
YBX3-355S-8	132kW	259.6	740	94.2	0.82	90	11.37	1.8	6.4	2	1800
YBX3-355M-8	160kW	313.8	740	94.2	0.82	90	13.7	1.8	6.4	2	1980
YBX3-355L1-8	185kW	362.9	740	94.2	0.82	90	13.7	1.8	6.4	2	2150
YBX3-355L2-8	200kW	386.3	740	94.5	0.83	90	16.33	1.8	6.4	2	2200
YBX3-315S-10	45kW	99.4	590	91.5	0.75	82	3.82	1.5	6.2	2	890
YBX3-315M-10	55kW	121.1	590	92	0.75	82	4.6	1.5	6.2	2	1000
YBX3-315L1-10	75kW	162.1	590	92.5	0.76	82	4.94	1.5	5.8	2	1120
YBX3-315L2-10	90kW	191	590	93	0.77	82	5.63	1.5	5.9	2	1190
YBX3-355S-10	90kW	191	590	93	0.77	82	14.12	1.5	6	2	1715
YBX3-355M1-10	110kW	230	590	93.2	0.78	90	14.12	1.3	6	2	1890
YBX3-355M2-10	132kW	275	590	93.5	0.78	90	16.07	1.3	6	2	2020
YBX3-355L1-10	160kW	332.4	590	93.5	0.78	90	17.29	1.3	6	2	2240
YBX3-355L2-10	185kW	384.3	590	93.5	0.78	90	18.36	1.3	6	2	2365
YBX3-355L2-10	200kW	410.9	590	93.6	0.79	90	19.48	1.3	6	2	2445
