Filterable Table with Fixed Header
电机型号 | 堵转转矩 | 堵转电流 | 功率(KW) | 动态常数FC=15% | 动态常数FC=25% | 动态常数FC=40% | 动态常数FC=60% | 转动惯量(kg·m²) | 重量(kg) |
---|---|---|---|---|---|---|---|---|---|
YGa112L1-4 | 22 | 13 | 1.2 | 94 | 92 | 90 | 86 | 0.0112 | 57 |
YGa112L2-4 | 36 | 19 | 1.8 | 140 | 135 | 130 | 125 | 0.0166 | 66 |
YGa112L1-6 | 22 | 8.5 | 0.8 | 215 | 210 | 205 | 200 | 0.0112 | 57 |
YGa112L2-6 | 34 | 12 | 1.2 | 290 | 285 | 280 | 270 | 0.0166 | 66 |
YGa112L1-8 | 17 | 5.6 | 0.45 | 350 | 345 | 335 | 320 | 0.0112 | 57 |
YGa112L2-8 | 28 | 9 | 0.75 | 495 | 485 | 470 | 450 | 0.0166 | 66 |
YGa112L1-10 | 16 | 4.5 | 0.32 | 520 | 510 | 490 | 465 | 0.0112 | 57 |
YGa112L2-10 | 25 | 7.5 | 0.5 | 700 | 685 | 660 | 625 | 0.0166 | 66 |
YGa112L1-12 | 22 | 5.3 | 0.3 | 1060 | 1030 | 990 | 930 | 0.0166 | 66 |
YGa132M1-6 | 50 | 18 | 1.7 | 315 | 310 | 300 | 290 | 0.0251 | 90 |
YGa132M2-6 | 71 | 24 | 2.4 | 390 | 380 | 375 | 360 | 0.0333 | 98 |
YGa132M1-8 | 42 | 12 | 1.1 | 530 | 520 | 510 | 480 | 0.0251 | 90 |
YGa132M2-8 | 60 | 17 | 1.6 | 670 | 655 | 640 | 605 | 0.0333 | 98 |
YGa132M1-10 | 38 | 9 | 0.75 | 790 | 770 | 740 | 700 | 0.0251 | 90 |
YGa132M2-10 | 56 | 13 | 1.1 | 990 | 970 | 930 | 880 | 0.0333 | 98 |
YGa132M1-12 | 36 | 8 | 0.56 | 1130 | 1090 | 1050 | 990 | 0.0251 | 90 |
YGa132M2-12 | 53 | 11 | 0.85 | 1400 | 1360 | 1300 | 1220 | 0.0333 | 98 |
YGa160S1-8 | 80 | 22 | 2.2 | 810 | 790 | 770 | 730 | 0.0646 | 131 |
YGa160S2-8 | 110 | 30 | 3 | 1010 | 990 | 950 | 910 | 0.0841 | 142 |
YGa160L1-8 | 150 | 40 | 4 | 1230 | 1200 | 1160 | 1110 | 0.114 | 172 |
YGa160L2-8 | 210 | 56 | 5.3 | 1470 | 1430 | 1380 | 1310 | 0.139 | 190 |
YGa160S1-10 | 80 | 18 | 1.6 | 1220 | 1190 | 1150 | 1090 | 0.0646 | 131 |
YGa160S2-10 | 110 | 24 | 2.2 | 1470 | 1440 | 1380 | 1300 | 0.0814 | 142 |
YGa160L1-10 | 150 | 32 | 3 | 1880 | 1830 | 1760 | 1670 | 0.114 | 172 |
YGa160L2-10 | 200 | 40 | 3.8 | 2260 | 2200 | 2120 | 2000 | 0.139 | 190 |
YGa160S1-12 | 75 | 15 | 1.2 | 1670 | 1620 | 1550 | 1440 | 0.0646 | 131 |
YGa160S2-12 | 105 | 20 | 1.6 | 2060 | 2000 | 1910 | 1780 | 0.0814 | 142 |
YGa160L1-12 | 140 | 26 | 2.2 | 2590 | 2510 | 2400 | 2230 | 0.114 | 172 |
YGa160L2-12 | 190 | 34 | 3 | 3120 | 3020 | 2880 | 2680 | 0.1396 | 190 |
YGa160S1-16 | 50 | 9.5 | 0.48 | 2770 | 2660 | 2500 | 2290 | 0.0646 | 131 |
YGa160S2-16 | 75 | 13 | 0.75 | 3390 | 3250 | 3050 | 2770 | 0.0814 | 142 |
YGa160L1-16 | 105 | 18 | 1.1 | 4340 | 4160 | 3990 | 3540 | 0.114 | 172 |
YGa160L2-16 | 140 | 24 | 1.6 | 5170 | 4950 | 4640 | 4180 | 0.139 | 190 |
YGa180L1-8 | 280 | 67 | 6.7 | 1640 | 1600 | 1540 | 1460 | 0.237 | 229 |
YGa180L1-10 | 250 | 48 | 4.8 | 2500 | 2440 | 2350 | 2220 | 0.237 | 229 |
YGa180L2-10 | 320 | 60 | 6 | 2880 | 2810 | 2690 | 2530 | 0.294 | 252 |
YGa180L1-12 | 250 | 42 | 4 | 3600 | 3500 | 3340 | 3130 | 0.237 | 229 |
YGa180L2-12 | 320 | 53 | 5 | 4180 | 4050 | 3860 | 3610 | 0.294 | 252 |
YGa180L1-16 | 190 | 30 | 2.2 | 5850 | 5610 | 5270 | 4800 | 0.237 | 229 |
YGa180L2-16 | 250 | 38 | 3 | 6950 | 6670 | 6260 | 5710 | 0.294 | 252 |
YGa200L1-10 | 400 | 75 | 7.5 | 3260 | 3180 | 3050 | 2880 | 0.529 | 302 |
YGa200L2-10 | 500 | 95 | 9.5 | 3790 | 3690 | 3530 | 3320 | 0.631 | 337 |
YGa200L1-12 | 400 | 63 | 6.3 | 4650 | 4500 | 4290 | 4010 | 0.509 | 302 |
YGa200L2-12 | 500 | 80 | 8 | 5470 | 5300 | 5040 | 4700 | 0.631 | 337 |
YGa200L1-16 | 320 | 50 | 4 | 7890 | 7580 | 7100 | 6490 | 0.509 | 302 |
YGa200L2-16 | 420 | 63 | 5.3 | 9100 | 8710 | 8100 | 7370 | 0.631 | 337 |
YGa200L1-20 | 250 | 36 | 2 | 11210 | 10630 | 9750 | 8590 | 0.509 | 302 |
YGa200L2-20 | 340 | 48 | 2.8 | 12980 | 12250 | 11150 | 9690 | 0.631 | 337 |
YGa225M1-10 | 630 | 125 | 12 | 3870 | 3740 | 3550 | 3280 | 0.91 | 410 |
YGa225M2-10 | 800 | 150 | 15 | 4440 | 4290 | 4050 | 3740 | 1.11 | 445 |
YGa225M1-12 | 630 | 100 | 10 | 5550 | 5350 | 5050 | 4650 | 0.91 | 410 |
YGa225M2-12 | 800 | 130 | 12 | 6330 | 6080 | 5710 | 5220 | 1.11 | 445 |
YGa225M1-16 | 530 | 80 | 6.7 | 9380 | 8950 | 8310 | 7460 | 0.91 | 410 |
YGa225M2-16 | 670 | 100 | 8.5 | 10770 | 10250 | 9460 | 8400 | 1.11 | 445 |
YGa225M1-20 | 450 | 63 | 3.6 | 13830 | 12990 | 11760 | 10050 | 0.91 | 410 |
YGa225M2-20 | 560 | 80 | 4.5 | 15750 | 14760 | 13300 | 11280 | 1.11 | 445 |
