YBBP Series Variable-Frequency and Variable-speed Flameproof Electric Motors 80-355

Home Products Electric Motors Low Voltage Electric Motors YBBP Series Variable-Frequency and Varia

Description

Spefication of YBBP Variable Frequency Flameproof Motor 80-355

Spefication of YBBP Variable Frequency Flameproof Motor 80-355

Frame Size Power
(KW) 		Current
（A）
380V 		Current
（A）
660V 		Current
（A）
1140V 		Speed
50HZ 		Efficiency
(%) 		Powerfactor
（cosΦ） 		Noise
dB(A) 		Vibration
(mm/s) 		Tst/Tn Ist/In Tmax/Tn Weight
(Kg)
YBBP-80M1-2 0.75kW 1.83 1.05 0.61 2825 75 0.83 67 1.8 2.2 6 2.3 30
YBBP-80M2-2 1.1kW 2.55 1.47 0.85 2825 78 0.84 67 1.8 2.2 6 2.3 32
YBBP-90S-2 1.5kW 3.43 1.97 1.14 2840 79 0.84 72 1.8 2.2 7 2.3 38
YBBP-90L-2 2.2kW 4.85 2.79 1.62 2840 81 0.85 72 1.8 2.2 7 2.3 41
YBBP-100L-2 3kW 6.24 3.59 2.08 2880 83 0.88 76 1.8 2.2 7 2.3 51
YBBP-112M-2 4kW 8.12 4.68 2.71 2890 85 0.88 77 1.8 2.2 7 2.3 63
YBBP-132S1-2 5.5kW 11 6.33 3.67 2900 86 0.88 80 1.8 2.2 7.5 2.3 87
YBBP-132S2-2 7.5kW 14.9 8.58 4.97 2900 87 0.88 80 1.8 2.2 7.5 2.3 91
YBBP-160M1-2 11kW 21.5 12.38 7.17 2930 88.4 0.88 86 2.8 2.2 7.5 2.4 140
YBBP-160M2-2 15kW 28.6 16.47 9.53 2930 89.4 0.89 86 2.8 2.2 7.5 2.4 150
YBBP-160L-2 18.5kW 35.1 20.21 11.7 2930 90 0.89 86 2.8 2.2 7.5 2.4 170
YBBP-180M2 22kW 41 23.61 13.67 2940 90.5 0.9 89 2.8 2 7.5 2.4 195
YBBP-200L1-2 30kW 55.4 31.9 18.47 2950 91.4 0.9 92 2.8 2 7.5 2.4 268
YBBP-200L2-2 37kW 67.9 39.09 22.63 2950 92 0.9 92 2.8 2 7.5 2.4 288
YBBP-225M-2 45kW 82.1 47.27 27.37 2970 92.5 0.9 92 2.8 2 7.5 2.3 373
YBBP-250M-2 55kW 99.8 57.46 33.27 2970 93 0.9 93 3.5 2.1 7.5 2.3 491
YBBP-280S-2 75kW 133.8 77.04 44.6 2970 93.6 0.91 94 3.5 2 7.5 2.3 600
YBBP-280M-2 90kW 160 92.12 53.33 2970 93.9 0.91 94 3.5 2.1 7.5 2.3 650
YBBP-315S-2 110kW 195.4 112.5 65.13 2980 94 0.91 96 3.5 1.8 7 2.3 1050
YBBP-315M-2 132kW 233.2 134.27 77.73 2980 94.5 0.91 96 3.5 1.8 7 2.3 1130
YBBP-315L1-2 160kW 282.4 162.59 94.13 2980 94.6 0.91 99 3.5 1.8 7 2.3 1190
YBBP-315L2-2 200kW 348.4 200.59 116.13 2980 94.8 0.92 99 3.5 1.8 7 2.3 1250
YBBP-355S1-2 185kW 326.5 187.98 108.83 2980 94.6 0.91 99 3.5 1.8 7 2.3 1710
YBBP-355S2-2 200kW 348.4 200.59 116.13 2980 94.8 0.92 99 3.5 1.8 7 2.3 1720
YBBP-355M1-2 220kW 383.2 220.63 127.73 2980 94.8 0.92 103 3.5 1.6 7 2.4 1920
YBBP-355M2-2 250kW 433.7 249.71 144.57 2980 95.2 0.92 103 3.5 1.6 7 2.4 1970
YBBP-355L1-2 280kW 485.7 279.65 161.9 2980 95.2 0.92 103 3.5 1.6 7 2.4 2080
YBBP-355L2-2 315kW 545.3 313.96 181.77 2980 95.4 0.92 103 3.5 1.6 7 2.4 2210
YBBP-80M1-4 0.55kW 1.57 0.9 0.52 1390 71 0.75 58 1.8 2.4 5 2.3 29
YBBP-80M2-4 0.75kW 2.03 1.17 0.68 1390 73 0.77 58 1.8 2.4 5 2.3 30
YBBP-90S-4 1.1kW 2.89 1.66 0.96 1400 76.2 0.77 61 1.8 2.3 6 2.3 37
YBBP-90L-4 1.5kW 3.7 2.13 1.23 1400 78.5 0.79 61 1.8 2.3 6 2.3 41
YBBP-100L1-4 2.2kW 5.16 2.97 1.72 1420 81 0.81 64 1.8 2.3 6 2.4 50
YBBP-100L2-4 3kW 6.78 3.9 2.26 1420 82.6 0.82 64 1.8 2.3 6 2.4 53
YBBP-112M-4 4kW 8.82 5.08 2.94 1440 84.2 0.82 65 1.8 2.3 6 2.4 67
YBBP-132S-4 5.5kW 11.6 6.68 3.87 1440 86 0.84 71 1.8 2.3 7 2.4 87
YBBP-132M-4 7.5kW 15.4 8.87 5.13 1440 87 0.85 71 1.8 2.3 7 2.4 100
YBBP-160M-4 11kW 22.3 12.84 7.43 1460 88.4 0.85 75 2.8 2.2 7 2.4 145
YBBP-160L-4 15kW 30.1 17.33 10.03 1460 89.4 0.85 75 2.8 2.2 7 2.4 165
YBBP-180M-4 18.5kW 36.5 21.02 12.17 1470 90.5 0.85 76 2.8 2.2 7 2.3 210
YBBP-180L-4 22kW 43.1 24.82 14.37 1470 91.2 0.85 76 2.8 2.2 7 2.3 220
YBBP-200L-4 30kW 57.6 33.16 19.2 1470 92 0.86 79 2.8 2.2 7.2 2.4 280
YBBP-225S-4 37kW 69.9 40.25 23.3 1480 92.5 0.87 81 2.8 2.2 7.2 2.4 350
YBBP-225M-4 45kW 84.7 48.77 28.23 1480 92.8 0.87 81 2.8 2.2 7.2 2.4 390
YBBP-250M-4 55kW 103.3 59.48 34.43 1480 93 0.87 83 3.5 2.2 7.2 2.4 505
YBBP-280S-4 75kW 139.6 80.38 46.53 1480 93.8 0.87 86 3.5 2.2 7.2 2.4 645
YBBP-280M-4 90kW 166.8 96.04 55.6 1480 94.2 0.87 86 3.5 2.2 7.2 2.4 712
YBBP-315S-4 110kW 201 115.73 67 1485 94.5 0.88 93 3.5 2.1 7 2.4 1090
YBBP-315M-4 132kW 240.4 138.41 80.13 1485 94.8 0.88 93 3.5 2.1 7 2.4 1180
YBBP-315L1-4 160kW 287.8 165.7 95.93 1485 94.9 0.89 97 3.5 2.1 7 2.4 1250
YBBP-315L2-4 200kW 359.8 207.16 119.93 1485 94.9 0.89 97 3.5 2.1 7 2.3 1350
YBBP-355S1-4 185kW 332.8 191.61 110.93 1488 94.9 0.89 97 3.5 2.1 7 2.4 1700
YBBP-355S2-4 200kW 355.8 204.85 118.6 1488 94.9 0.9 97 3.5 2.1 7 2.3 1750
YBBP-355M1-4 220kW 391.4 225.35 130.47 1488 94.9 0.9 101 3.5 2.1 7 2.4 1920
YBBP-355M2-4 250kW 443.3 255.23 147.77 1488 95.2 0.9 101 3.5 2.1 7 2.4 1920
YBBP-355L1-4 280kW 496.5 285.86 165.5 1488 95.2 0.9 101 3.5 2.1 7 2.4 2120
YBBP-355L2-4 315kW 558.6 321.62 186.2 1488 95.2 0.9 101 3.5 2.1 7 2.4 2120
YBBP-80M1-6 0.37kW 1.27 0.73 0.42 910 63 0.7 54 1.8 1.9 4 2.1 30
YBBP-80M2-6 0.55kW 1.76 1.01 0.59 910 66 0.72 54 1.8 1.9 4 2.1 32
YBBP-90S-6 0.75kW 2.29 1.32 0.76 910 69 0.72 57 1.8 2.1 4 2.1 37
YBBP-90L-6 1.1kW 3.14 1.81 1.05 910 73 0.73 57 1.8 2.1 5 2.1 40
YBBP-100L-6 1.5kW 3.95 2.27 1.32 940 76 0.76 61 1.8 2.1 5 2.1 49
YBBP-112M-6 2.2kW 5.57 3.21 1.86 940 79 0.76 65 1.8 2.1 5 2.1 86
YBBP-132S-6 3kW 7.31 4.21 2.44 960 81 0.77 69 1.8 2.1 6 2.4 83
YBBP-132M1-6 4kW 9.39 5.41 3.13 960 83 0.78 69 1.8 2.1 6 2.4 92
YBBP-132M2-6 5.5kW 12.6 7.25 4.2 960 85 0.78 69 1.8 2.1 6.5 2.4 100
YBBP-160M-6 7.5kW 16.8 9.67 5.6 970 86 0.79 73 2.8 2.1 6.5 2.4 140
YBBP-160L-6 11kW 24.2 13.93 8.07 970 87.5 0.79 73 2.8 2.1 6.5 2.4 164
YBBP-180L-6 15kW 31.6 18.19 10.53 970 89 0.81 73 2.8 2.1 7 2.1 212
YBBP-200L1-6 18.5kW 37.6 21.65 12.53 970 90 0.83 76 2.8 2.2 7 2.4 260
YBBP-200L2-6 22kW 44.7 25.74 14.9 970 90 0.83 76 2.8 2.2 7 2.4 273
YBBP-225M-6 30kW 57.6 33.16 19.2 980 92 0.86 76 2.8 2.1 7 2.4 363
YBBP-250M-6 37kW 71 40.88 23.67 980 92 0.86 78 3.5 2.1 7 2.4 478
YBBP-280S-6 45kW 85.9 49.46 28.63 980 92.5 0.86 80 3.5 2.1 7 2.4 600
YBBP-280M-6 55kW 104.7 60.28 34.9 980 92.8 0.86 80 3.5 2.1 7 2.3 650
YBBP-315S-6 75kW 141.7 81.58 47.23 985 93.5 0.86 85 3.5 2 7 2.2 1020
YBBP-315M-6 90kW 169.5 97.59 56.5 985 93.8 0.86 85 3.5 2 7 2.2 1130
YBBP-315L1-6 110kW 206.7 119.01 68.9 985 94 0.86 85 3.5 2 7 2.2 1220
YBBP-315L2-6 132kW 244.7 140.89 81.57 985 94.2 0.87 85 3.5 2 7 2.2 1290
YBBP-355S-6 160kW 292.3 168.29 97.43 985 94.5 0.88 92 3.5 2 7 2.2 1870
YBBP-355M1-6 185kW 338 194.61 112.67 985 94.5 0.88 92 3.5 2 7 2.2 2050
YBBP-355M2-6 200kW 365.4 210.38 121.8 985 94.5 0.88 92 3.5 2 7 2.2 2110
YBBP-355L1-6 220kW 402 231.45 134 985 94.5 0.88 92 3.5 2 7 2.2 2220
YBBP-355L2-6 250kW 456.8 263.01 152.27 985 94.5 0.88 92 3.5 2 7 2.2 2270
YBBP-80M1-8 0.18kW 0.86 0.5 0.29 710 52 0.61 52 1.8 1.8 3.3 1.9 31
YBBP-80M2-8 0.25kW 1.13 0.65 0.38 710 55 0.61 52 1.8 1.8 3.3 1.9 32
YBBP-90S-8 0.37kW 1.44 0.83 0.48 710 63 0.62 56 1.8 1.8 4 2 38
YBBP-90L-8 0.55kW 2.07 1.19 0.69 710 64 0.63 56 1.8 1.8 4 2 41
YBBP-100L1-8 0.75kW 2.36 1.36 0.79 710 71 0.68 59 1.8 1.8 4 2 47
YBBP-100L2-8 1.1kW 3.32 1.91 1.11 710 73 0.69 59 1.8 1.8 4 2 49
YBBP-112M-8 1.5kW 4.4 2.53 1.47 710 75 0.69 61 1.8 1.8 4 2 65
YBBP-132S-8 2.2kW 5.8 3.34 1.93 710 79 0.73 64 1.8 1.8 5.5 2.2 83
YBBP-132M-8 3kW 7.71 4.44 2.57 710 81 0.73 64 1.8 1.8 5.5 2.2 92
YBBP-160M1-8 4kW 10.3 5.93 3.43 720 81 0.73 68 2.8 1.9 6 2.2 123
YBBP-160M2-8 5.5kW 13.4 7.72 4.47 720 83 0.75 68 2.8 1.9 6 2.2 137
YBBP-160L-8 7.5kW 17.6 10.13 5.87 720 85 0.76 68 2.8 1.9 6 2.2 161
YBBP-180L-8 11kW 25.3 14.57 8.43 730 87 0.76 70 2.8 1.9 6 2.2 208
YBBP-200L-8 15kW 33.7 19.4 11.23 730 89 0.76 73 2.8 2 6.5 2.2 268
YBBP-225S-8 18.5kW 40 23.03 13.33 730 90 0.78 73 2.8 2 6.5 2.2 334
YBBP-225M-8 22kW 47.4 27.29 15.8 730 90.5 0.78 73 2.8 2 6.5 2.2 362
YBBP-250M-8 30kW 63.4 36.5 21.13 730 91 0.79 75 3.5 1.9 6.5 2 442
YBBP-280S-8 37kW 77.8 44.79 25.93 740 91.5 0.79 76 3.5 1.8 6 2 606
YBBP-280M-8 45kW 94.1 54.18 31.37 740 92 0.79 76 3.5 1.8 6 2 663
YBBP-315S-8 55kW 111.2 64.02 37.07 740 92.8 0.81 82 3.5 1.9 6.5 2.2 1000
YBBP-315M-8 75kW 150.5 86.65 50.17 740 93.5 0.81 82 3.5 1.9 6.5 2.2 1160
YBBP-315L1-8 90kW 177.8 102.37 59.27 740 93.8 0.82 82 3.5 1.9 6.5 2.2 1250
YBBP-315L2-8 110kW 216.8 124.82 72.27 740 94 0.82 82 3.5 1.9 6.5 2.2 1340
YBBP-355S-8 132kW 259.6 149.47 86.53 740 94.2 0.82 90 3.5 2 6.5 2.2 1870
YBBP-355M-8 160kW 314.7 181.19 104.9 740 94.2 0.82 90 3.5 2 6.5 2.2 2050
YBBP-355L1-8 185kW 363.9 209.52 121.3 740 94.2 0.82 90 3.5 2 6.5 2.2 2220
YBBP-355L2-8 200kW 387.4 223.05 129.13 740 94.5 0.83 90 3.5 2 6.5 2.2 2270
YBBP-315S-10 45kW 99.6 57.35 33.2 585 91.5 0.75 82 3.5 1.5 6 2.1 960
YBBP-315M-10 55kW 121.1 69.72 40.37 585 92 0.75 82 3.5 1.5 6 2.1 1070
YBBP-315L1-10 75kW 162.1 93.33 54.03 585 92.5 0.76 82 3.5 1.5 6 2.1 1190
YBBP-315L2-10 90kW 190.9 109.91 63.63 585 93 0.77 82 3.5 1.5 6 2.1 1260
YBBP-355S-10 90kW 190.9 109.91 63.63 585 93 0.77 82 3.5 1.5 6 2.1 1785
YBBP-355M1-10 110kW 229.9 132.37 76.63 585 93.2 0.78 90 3.5 1.3 5.5 2.1 1960
YBBP-355M2-10 132kW 275 158.33 91.67 585 93.5 0.78 90 3.5 1.3 5.5 2.1 2090
YBBP-355L1-10 160kW 333 191.73 111 585 93.5 0.78 90 3.5 1.3 5.5 2.1 2310
YBBP-355L2-10 185kW 385 221.67 128.33 585 93.5 0.78 90 3.5 1.3 5.5 2.1 2435
YBBP-355L3-10 200kW 410.9 236.58 136.97 585 93.6 0.79 90 3.5 1.3 5.5 2.1 2515
